440054-8
Manufacturer:
TE Connectivity
Mfr.Part #:
440054-8
Datasheet:
Description:
Headers and Wire Housings Through Hole Header, Pin, Plug Number of Positions:8 Pitch:2 mm
| Parameter | Value |
|---|---|
| Length | 18.00098 mm |
| Width | 4.7 mm |
| Termination | Solder, Through Hole |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Height | 6.0452 mm |
| Packaging | Bulk |
| Voltage Rating | 250 V |
| Depth | 4.7 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Contact Plating | Tin, Brass |
| Lead Length | 3.4036 mm |
| Contact Material(Contact Finish) | Brass |
| Pitch | 2 mm |
| Current Rating | 3 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Vertical |
| Operating Supply Voltage | 250 V |
| Lifecycle Status | Production (Last Updated: 1 week ago) |
| Color | Natural |
| Gender | Male |
| Number of Contacts | 8 |
| ELV | Compliant |
| Connector Type | Header, Pin, Plug |
| Wire/Cable Gauge | 24 AWG |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Connector System | Wire-to-Board |
| Contact Style | Straight |
| Max Voltage Rating (AC) | 250 V |
| Contact Current Rating | 3 A |
| Housing Color | Natural |
| Plating | Tin |
| Insulation Diameter | 900 µm |
| Contact Mating Length | 3.3528 mm |
| PCB Mounting Orientation | Vertical |
| PCB Thickness | 1.6 mm |
| Tail Length | 3.4 mm |
| Contact Gender | Male |
| Mating Post Length | 3.3274 mm |
| Contact Shape | Square |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 1 week ago) |
| Sealable | No |
| Mating Retention | Without |
| PCB Mount Retention | With |
| PCB Mount Alignment | Without |
Stock: 7266
Distributors
pcbx
pcbxUnit Price$0.26253
Ext.Price$0.26253
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.26253 | $0.26253 |
| 10 | $0.22152 | $2.21520 |
| 25 | $0.20979 | $5.24475 |
| 50 | $0.19868 | $9.93400 |
| 100 | $0.18816 | $18.81600 |
| 300 | $0.17819 | $53.45700 |
| 500 | $0.16875 | $84.37500 |
| 1000 | $0.15981 | $159.81000 |
| 3000 | $0.15135 | $454.05000 |
| 5000 | $0.14333 | $716.65000 |
| 10000 | $0.13574 | $1357.40000 |
